Creaform's optical measuring system uses photogrammetry

Dec. 20, 2011
The MaxSHOT 3D optical coordinate measuring system combines the MaxSHOT 3D photogrammetric video camera with VXshot processing software.

The MaxSHOT 3Doptical coordinate measuring system combines the MaxSHOT 3D photogrammetric video camera with VXshot processing software. Featuring real-time visualization and validation of acquired data and step-by-step operation, it simplifies generation of object positioning models.
Creaform
Lévis, QC, Canada

-- Posted byVision Systems Design

View More New Products

---
NEW PRODUCT PRESS RELEASE

Creaform Launches the MaxSHOT 3D Optical Coordinate Measuring System

LÉVIS, Quebec -- New photogrammetry camera enhances Creaform technology product offering

Creaform, a provider of portable 3D optical measurement technologies, is proud to introduce the
latest addition to the wide range of technologies it develops and manufactures, the MaxSHOT 3D optical coordinate measuring system.

he MaxSHOT 3D adds the accuracy and speed of photogrammetry to the wide
range of applications already possible with Creaform technologies, most
especially when it comes to larger parts. It combines the MaxSHOT 3D
photogrammetric video camera and the VXshot processing software.

"We are excited about this new system, since it reflects perfectly our
commitment to high accuracy and reliability, says Creaform's president
Charles Mony. The MaxSHOT 3D system brings photogrammetry to a whole new
level in terms of affordability, ease of use and accessibility. With the
MaxSHOT 3D, we will indisputably strengthen our position and grow our market
share in metrology-grade technologies on the international basis."

Features and Benefits

As product director Jean-François Larue stresses out, "our main goal
was to come up with the most user-friendly photogrammetry software that ever
existed to support our MaxSHOT 3D optical coordinate measurement system. We
are extremely proud to present the metrology/ quality control community with
an innovative software that is very simple to operate. Featuring real-time
visualization and validation of acquired data and an entirely guided
step-by-step operation, it allows even those new to photogrammetry to
quickly and easily generate a high accuracy positioning model of an object."

In concrete terms, using the MaxSHOT 3D with a Handyscan 3D
self-positioning scanner, a MetraSCAN optical CMM 3D scanner or a HandyPROBE
arm-free CMM translates into shorter measuring time on larger parts,
accelerated positioning of the device around the part and higher measurement
accuracy, which ultimately leads to reduced production costs and increased
efficiency.

About Creaform
Creaform specializes in 3D portable optical measurement technologies and
3D engineering services. We offer innovative solutions that cover the entire
range of 3D applications, including 3D scanning, reverse engineering,
inspection, design & engineering and FEA. Our wide range of products and
services are intended for industries such as the automotive, aerospace,
defence, consumer products, heritage preservation and manufacturing.

Creaform has developed and sells the Handyscan 3D line of
self-positioning 3D scanners, along with the HandyPROBE portable arm-free
CMM and the MetraSCAN optical CMM 3D scanner, two systems designed for
inspection applications. It has recently launched the MaxSHOT 3D optical
coordinate measuring system that brings photogrammetry to all these
technologies.

SOURCE:Creaform
